LM2901AVQPWRQ1
Features for the LM2901AV-Q1
Qualified for automotive applications
AEC-Q100 Qualified with the following results:
Device temperature grade 1: –40°C to 125°C ambient operating temperature range
Device HBM ESD classification levels:
H1B for "AV" version
H1C for all other versions
Device CDM ESD classification level C6
Single supply or dual supplies
Low supply-current drain independent of supply voltage 0.8mA (typical)
Low input bias current 25 nA (typical)
Low input offset current 2 nA (typical)
Low input offset voltage 2mV Typ (typical)
Common-mode input voltage range includes ground
Differential input voltage range equal to maximum-rated supply voltage ±36 V
Low output saturation voltage
Output compatible with TTL, MOS, and CMOS
For single version in 5-pin SOT-23, see the TL331-Q1 (SLVS969)
Description
REQUEST A QUOTE
The LM2901x-Q1 family of devices consists of four independent voltage comparators, designed to operate from a single power supply over a wide range of voltages.
Operation from dual supplies is possible, provided the difference between the two supplies is 2 V to 36 V, and VCC is at least 1.5 V more positive than the input common-mode voltage. Current drain is independent of the supply voltage.
The outputs can be connected to other open-collector outputs to achieve wired-AND relationships.
LM2901V-Q1 supports higher 32 V supply voltage and LM2901AV-Q1 supports the higher 32 V supply voltage and lower offset voltage.
