CD74HC4052PWR
Features for the CD74HC4052
Wide Analog Input Voltage Range: ±5-V Maximum
Low ON-Resistance
70-Ω Typical (VCC – VEE = 4.5V)
40-Ω Typical (VCC – VEE = 9V)
Low Crosstalk Between Switches
Fast Switching and Propagation Speeds
Break-Before-Make Switching
Wide Operating Temperature Range:
–55°C to +125°C
CD54HC and CD74HC Types
Operation Control Voltage: 2 V to 6 V
Switch Voltage: 0 V to 10 V
CD54HCT and CD74HCT Types
Operation Control Voltage: 4.5 V to 5.5 V
Switch Voltage: 0 V to 10 V
Direct LSTTL Input Logic Compatibility
VIL = 0.8-V Max, VIH = 2-VMin
CMOS Input Compatibility
II ≤ 1 µA at VOL,VOH
On Products Compliant to MIL-PRF-38535,
All Parameters Are Tested Unless Otherwise Noted. On All Other Products, Production Processing Does Not Necessarily Include Testing of All Parameters.
Description
REQUEST A QUOTE
The CDx4HC405x and CDx4HCT405x devices are digitally controlled analog switches that usesilicon gate CMOS technology to achieve operating speeds similar to LSTTL with the low-powerconsumption of standard CMOS integrated circuits.
These analog multiplexers and demultiplexers control analog voltages that may vary acrossthe voltage supply range (for example, VCC to VEE).They are bidirectional switches that allow any analog input to be used as an output and vice versa.The switches have low ON resistance and low OFF leakages. In addition, all these devices have anenable control that, when high, disables all switches to their OFF state.
