KSZ8041NLI-TR
Features
KSZ8041NL 10Base-T/100Base-TX Physical Layer Transceiver
RJ-45 Jack for Fast Ethernet cable interface
HP Auto-MDIX for automatic detection and correction for straight-through and crossover cables
MII (Media Independent Interface) Connector to interface with a MAC controller
RMII (Reduced MII) option using MII Connector
2 LED Indicators for status and activity
Jumpers to configure strapping pins
Manual Reset Button for quick reboot after re-configuration of strapping pins
Description
REQUEST A QUOTE
The KSZ8041NL is a 10Base-T/100Base-TX Physical Layer Transceiver with MII and RMII MACinterfaces. It utilizes a unique mixed-signal design to extend signaling distance while reducingpower consumption, and offers HP Auto MDI/MDI-X for reliable detection of and correction for crossover and straight-through cables, eliminating the need to differentiate between crossover and straight-through cables. The KSZ8041NL comes in a 32-pin, lead-free MLF® (QFN per JDEC) package and provides an ideal solution for 10Base-T/100Base-TX applications that have tight PCB board space. The KSZ8041NL Eval Board (KSZ8041NL-EVAL) provides a convenient platform to evaluate the KSZ8041NL features. All KSZ8041NL configuration pins are accessible either by jumpers, test points or interface connectors.
