FEATURES:
Standard Voltage: VDD and VDDQ = 1.5V ± 0.075V
Low Voltage (L): VDD and VDDQ = 1.35V + 0.1V, -0.067V
Backward compatible to 1.5V
High speed data transfer rates with system frequency up to 1066 MHz
8 internal banks for concurrent operation
8n-Bit pre-fetch architecture
Programmable CAS Latency
Programmable Additive Latency: 0, CL-1,CL-2
Programmable CAS WRITE latency (CWL) based on tCK
Programmable Burst Length: 4 and 8
Programmable Burst Sequence: Sequential or
Interleave
BL switch on the fly
Auto Self Refresh(ASR)
Self Refresh Temperature (SRT)
Refresh Interval:
7.8 μs (8192 cycles/64 ms) Tc= -40°C to 85°C 3.9 μs (8192 cycles/32 ms) Tc= 85°C to 105°C 1.95 μs (8192 cycles/16 ms) Tc= 105°C to 115°C 0.97 μs (8192 cycles/8 ms) Tc= 115°C to 125°C
NOVEMBER 2020
Asynchronous RESET pin
TDQS (Termination Data Strobe) supported (x8 only) OCD (Off-Chip Driver Impedance Adjustment)
Dynamic ODT (On-Die Termination)
Driver strength : RZQ/7, RZQ/6 (RZQ = 240 Ω) Write Leveling
Up to 200 MHz in DLL off mode
Operating temperature:
Commercial (TC = 0°C to +95°C)
Industrial (TC = -40°C to +95°C)
Automotive, A1 (TC = -40°C to +95°C)
Automotive, A2 (TC = -40°C to +105°C)
Automotive, A25 (TC = -40°C to +115°C) Automotive, A3 (TC = -40°C to +125°C)
