TLE7230R
1、Summary of Features：
Protection:Overload, short circuit;Overtemperature;Overvoltage
Low Quiescent Current< 10μA
16 bit SPI (for Daisychain)
Direct Parallel Control of Four Channels
PWM input (demux)
Parallel Inputs High or Low Active Programmable
Programmable functions:Boolean operation,Overload behavior,Overtemperature behavior,Switching time
General Fault Flag
Digital Ports Compatible to 5V and 3,3 V Micro Controllers
Electrostatic Discharge (ESD) Protection
Full reverse current capability without latch up
Green Product (RoHS compliant)
AEC qualified
2、Benefits：
Less Microcontr. I/Os needed
Protection of load and device
Reduced PCB space
Improved reliability
Less external components
Cost savings
3、Potential Applications：
Body Control Modules
Door Modules
ECU‘s
Industri
Description
REQUEST A QUOTE
The TLE 7230 R is an Octal Low-Side Switch in Smart Power Technology (SPT) with a Serial Peripheral Interface (SPI) and eight open drain DMOS output stages
It is protected by embedded protection functions and designed for automotive and industrial applications. The output stages are controlled via an SPI Interface. Additionally, four channels can be controlled in parallel for PWM applications. These features make the TLE 7230 R particularly suitable for engine management and body systems.
