TLE6209R
1、Summary of Features
Delivers up to 6 A continuous and 7 A peak current
Optimized for DC motor management applications
Very low R DS ON of typ. 150 mΩ @ 25 °C per switch
Operates at supply voltages of up to 40V
Overvoltage Protection against transients up to 45 V
Outputs fully short circuit protected
Standard SPI-Interface, daisy chain capability
Adjustable chopper current regulation of up to 7 A
Temperature monitor with prewarning, warning and shutdown
Over- and Undervoltage-Lockout
Open load detection
Detailed load failure diagnosis by SPI
Minimized power dissipation due to active free-wheeling
Low EMI due to voltage slope regulation
Very low current consumption (typ. 20 μA @ 25 °C) in stand-by (Inhibit) mode
Green Product (RoHS compliant)
AEC Qualified
2、Benefits
Full protection and diagnosis capability enables for use in safety relevant applications, covers full automotive temperature range
No external freewheeling diodes required
SPI interface enables bidrectional communictation with microcontroller
3、Potential Applications
Electronic Throttle Control
Exhaust Gas Recirculation System
Variable Turbo Geometry
Waste Gate
Resonant Charging Flaps
Swirl & Tumble flaps
Variable Valve timing
Description
REQUEST A QUOTE
The TLE 6209 R is an integrated power H-Bridge with D-MOS output stages for driving bidirectional loads such as DC-Motors
The design is based on Infineons Smart Power Technology SPT which allows bipolar, CMOS and power D-MOS devices on the same monolithic circuit. Operation modes forward (cw), reverse (ccw) and brake are invoked by two control pins PWM and DIR.
Protection and a reliable diagnosis of overcurrent, openload, short-circuit to ground, to the supply voltage or across the load are integrated. Detailed diagnostic information is given via the 8 bit SPI status word. An integrated chopper current limitation limits the current e.g. to reduce power dissipation during mechanical block of a DC motor. Several device parameters can be set by the SPI control word. A three-level temperature monitoring with prewarning, warning and shutdown is included for controlled operation under critical power loss conditions.
