TLE42754D
1、Summary of Features
Output Voltage 5 V ± 2%
Output Current up to 450 mA
Very low Current Consumption
Power-on and Under voltage Reset with Programmable Delay Time
Reset Low Down to V Q ; = 1 V
Very Low Dropout Voltage
Output Current Limitation
Reverse Polarity Protection
Over temperature Protection
Suitable for Use in Automotive Electronics
Wide Temperature Range from -40 °C up to 150 °C
Input Voltage Range from -42 V to 45 V
Green Product (RoHS compliant)
AEC Qualified
2、Benefits
Robust protection features
Wide input operation and temperature range
3、Potential Applications
Automotive general
Description
REQUEST A QUOTE
The TLE42754D is a monolithic integrated low-dropout voltage regulator in a 5-pin TO-package, especially designed for automotive applications.
An input voltage up to 42 V is regulated to an output voltage of 5.0 V. The component is able to drive loads up to 450 mA. It is short-circuit proof by the implemented current limitation and has an integrated over temperature shutdown. A reset signal is generated for an output voltage V Q,rt of typically 4.65 V. The power-on reset delay time can be programmed by the external delay capacitor.
