BTS7040-1EPA

1、Summary of Features

Basic Features

High-Side Switch with Diagnosis and Embedded Protection

Part of PROFET™+2 12V Family

Rever Save for low power dissipation in Reverse Polarity

Switch ON capability while Inverse Current condition (InverseON)

Green Product (RoHS compliant)

Qualified in accordance with AEC Q100 grade 1

2、Protection Features

Absolute and dynamic temperature limitation with controlled restart

Overcurrent protection (tripping) with Intelligent Restart Control

Undervoltage shutdown

Overvoltage protection with external components

3、Diagnostic Features

Proportional load current sense

Open Load in ON and OFF state

Short circuit to ground and battery

4、Potential Applications

Suitable for resistive, inductive and capacitive loads

Replaces electromechanical relays, fuses and discrete circuits

Driving capability suitable for 4.5 A loads and high inrush current loads such as P27W + R5W lamps or LED equivalent
