ADV7513BSWZ
FEATURES
General
Incorporates HDMI v1.4 features, including
3D video support
165 MHz supports all video formats up to 1080p
and UXGA
Supports gamut metadata packet transmission
Integrated CEC buffer/controller
Compatible with DVI v1.0 and HDCP v1.4
Video/audio inputs accept logic levels from 1.8 V to 3.3 V
Digital audio SCL
Supports standard S/PDIF for stereo linear pulse code modulation (LPCM) or compressed audio up to 192 kHz
High bit rate (HBR) audio
8-channel uncompressed LPCM I2S audio up to 192 kHz Special features for easy system design
5 V tolerant I2C and Hot PlugTM detect (HPD) I/Os, no extra device needed
No audio master clock needed for supporting S/PDIF and I2S
On-chip MPU with I2C master performs HDCP operations and EDID reading operations
On-chip MPU reports HDMI events through interrupts and registers
Description
REQUEST A QUOTE
The ADV7513 is a 165 MHz, High-Definition Multimedia Interface (HDMI®) transmitter that is ideal for DVD players/ recorders, digital set-top boxes, A/V receivers, gaming consoles, and PCs.
The digital video interface contains an HDMI v1.4/DVI v1.0- compatible transmitter and supports all HDTV formats. The ADV7513 supports HDMI v1.4-specific features, including 3D video. The ADV7513 also supports x.v.ColorTM, high bit rate (HBR) audio, and the programmable auxiliary video information (AVI) InfoFrame features. With the inclusion of HDCP, the ADV7513 allows the secure transmission of protected content as specified by the HDCP v1.4 protocol.
The ADV7513 supports both S/PDIF and 8-channel I2S audio. Its high fidelity 8-channel I2S interface can transmit either stereo or 7.1 surround audio up to 768 kHz. The S/PDIF interface can carry compressed audio, including Dolby® Digital, DTS®, and THX®. Fabricated in an advanced CMOS process, the ADV7513 is provided in a 64-lead LQFP surface-mount plastic package with exposed pad and is specified over the −25°C to +85°C temperature range.
