TPS7A9201DSKR
Features for the TPS7A92
1.0% Accuracy Over Line, Load, and Temperature
Low Output Noise: 4.6 µVRMS (10 Hz–100 kHz)
Low Dropout: 180 mV (Typ) at 2 A
Wide Input Voltage Range: 1.4 V to 6.5 V
Wide Output Voltage Range: 0.8 V to 5.2 V
High Power-Supply Ripple Rejection (PSRR):
60 dB at DC
40 dB at 100 kHz
40 dB at 1 MHz
Fast Transient Response
Adjustable Start-Up In-Rush Control With Selectable Soft-Start Charging Current
Open-Drain Power-Good (PG) Output
RθJC = 3.2°C/W
Stable With a 22-µF or Larger Ceramic Output Capacitor
2.5-mm × 2.5-mm, 10-Pin WSON Package
Description
REQUEST A QUOTE
The TPS7A92 is a low-noise (4.8 µVRMS), low-dropout(LDO) voltage regulator capable of sourcing 2 A with only 180 mV of dropout.
The TPS7A92 output is adjustable with external resistors from 0.8 V to 5.2 V. TheTPS7A92 wide input-voltage range supports operation as low as 1.4 V and up to 6.5 V.
With 1% output voltage accuracy (over line, load, and temperature) and soft-startcapabilities to reduce in-rush current, the TPS7A92 is ideal for powering sensitive analoglow-voltage devices [such as voltage-controlled oscillators (VCOs), analog-to-digital converters(ADCs), digital-to-analog converters (DACs), high-end processors, and field-programmable gatearrays (FPGAs)].
The TPS7A92 is designed to power noise-sensitive components such as those found inhigh-speed communication, video, medical, or test and measurement applications. The very low4.6-µVRMS output noise and wideband PSRR (40 dB at 1 MHz) minimizes phasenoise and clock jitter. These features maximize performance of clocking devices, ADCs, andDACs.
