TPS2H160BQPWPRQ1
Features for the TPS2H160-Q1
Qualified for Automotive Applications
AEC-Q100 Qualified With the Following Results:
Device Temperature Grade 1: –40°C to 125°C Ambient Operating TemperatureRange
Device HBM ESD Classification Level H2
Device CDM ESD Classification Level C4B
Functional safety capable
Documentation available to aid functional safety systemdesign
Dual-Channel 160-mΩ Smart High-Side Switch With Full Diagnostics
Version A: Open-Drain Status Output
Version B:Current-Sense Analog Output
Wide Operating Voltage 3.4 to 40 V
Ultralow Standby Current, < 500 nA
High-Accuracy Current Sense:
±17% Under >25-mA Load
Adjustable Current Limit With External Resistor ±15% Under >500-mA Load
Protection:
Short-to-GND Protection by Current Limit (Internal orExternal)
Thermal Shutdown With Latch-Off Option and ThermalSwing
Inductive Load Negative Voltage Clamp With Optimized SlewRate
Loss of GND and Loss of Battery Protection
Diagnostic:
Overcurrent and Short to Ground Detection
Open-Load andShort-to-Battery Detection
Global Fault for Fast Interrupt
16-Pin Thermally-Enhanced PWP Package
Description
REQUEST A QUOTE
The TPS2H160-Q1 family is a fully-protected dual-channel smart high-side switch, withintegrated 160-mΩ NMOS power FETs.
Full diagnostics and high-accuracy current-sense features enable intelligent control ofthe load.
An external adjustable current limit improves reliability of the whole system by limitingthe inrush or overload current.
