TJA1145ATK/0Z
Features
1、General Features:
ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 compliant
Data rates up to 5 Mbit/s in the CAN FD fast phase
2、Autonomous bus biasing:
TJA1145ATK/FD supports FD passive behaviour to CAN FD data
Fully compatible with the TJA1145, with improved EMC performance
3、Designed for Automotive Applications:
±6 kV ESD protection, according to IEC TS 62228 on pins BAT and WAKE and on the CAN bus pins
CAN bus pins short-circuit proof to ±58 V
Suitable for use in 12 V and 24 V systems
AEC-Q100 qualified
4、Advanced ECU Power Management System:
Very low-current standby and sleep modes, with full wake-up capability
Entire node can be powered down via the inhibit output
Remote wake-up capability via HS CAN wake-up pattern or selective wake-up frame detection
Selective wake-up for bit rates up to 1 Mbit/s
Local wake-up via the WAKE pin
Wake-up source recognition
5、Protection and Diagnosis:
16-, 24- or 32-bit SPI for configuration, control and diagnosis
Transmit Data (TXD) dominant time-out function with diagnosis
Overtemperature warning and shut-down
Undervoltage detection and recovery on pins VCC, VIO and BAT
Cold start diagnosis (via bits PO and NMS)
Description
REQUEST A QUOTE
The TJA1145A is a high-speed CAN transceiver that provides an interface between a controller area network (CAN) protocol controller and the physical two-wire CAN bus. The transceiver is designed for high-speed CAN and CAN FD applications in the automotive industry, providing differential transmit and receive capability to a microcontroller with a CAN protocol controller.
TJA1145A supports reliable communication in the CAN FD fast phase at data rates up to 5 Mbit/s.
The TJA1145A features very low power consumption in standby and sleep modes and supports ISO 11898-2:2016 compliant CAN Partial Networking by means of a selective wake-up function.
