TLE4250-2G
1、Summary of Features
50 mA Output Current Capability
Tiny SMD-Package PG-SCT595-5 with lowest thermal resistance
Low Output Tracking Tolerance
Stable with Small Ceramic Output Capacitor
Low Dropout Voltage
Combined Reference / Enable Input
Low Current Consumption in Stand-by Mode
Maximum Input Voltage -42 V ≤ V I ≤ +45 V
Reverse Polarity Protection
Output Short Circuit Proof to Ground and Supply
Overtemperature Protection
Temperature Range -40 °C ≤ T j ≤ 150 °C
Green Product (RoHS compliant)
AEC Qualified
2、Benefits
Efficient and accurate voltage replication
Heat distribution in the system
Robust tracking supply
3、Potential Applications
Sensor Supply
Heat distribution
Secondary µcontroller supply
Description
REQUEST A QUOTE
The TLE4250-2G is a monolithic integrated low dropout voltage tracker in a tiny SMD package PG-SCT595-5 with excellent thermal resistance.
It is designed to supply off-board loads (e.g. sensors) in automotive environments. The IC protects itself in case of overload, over temperature, reverse polarity as well as output short circuit to battery and ground. Supply voltages up to V I = 45 V are regulated to a reference voltage applied at the adjust input “ADJ” with high accuracy. The output “Q” is able to drive loads up to 50 mA. In order to reduce the quiescent current to a minimum, the TLE4250-2 can be switched to stand-by mode by setting the adjust/enable input “ADJ/EN” to “low”.
